RS485 Modbus Meter

EM519032 Three Phase DIN Rail Active & Reactive smart electronic energy meter

EM519032 is an enhanced power & energy meter that combines exceptional performance and easy installation to deliver a cost-effective solution for power monitoring applications. It supports IR Communication IEC1107 Protocol for real-time monitoring. It measures active and reactive energy, forward and reverse energy. 3 measurement modes can be set according to the synthesis code. This IR&RS485 meter has two display modes: automatic display and button-pressing display. It complies with international standard EN50470-1/3.

1. Brief introduction

EM519032 is an enhanced power & energy meter that combines exceptional performance and easy installation to deliver a cost-effective solution for power monitoring applications. It supports IR Communication IEC1107 Protocol for real-time monitoring. It measures active and reactive energy, forward and reverse energy. 3 measurement modes can be set according to the synthesis code. This IR&RS485 meter has two display modes: automatic display and button-pressing display. It complies with international standard EN50470-1/3.

Our Multimeter EM519032 is one of the few MID-calibrated 3-phase multimeter / 3-phase 400V meter (10 / 63A) with digital display for DIN rails. It is designed for quick snap-on mounting on DIN rails and is therefore suitable for installation in almost all fuse boxes and electrical boxes. The counter can record and display the following values for each phase:

• Electricity consumption (kWh kilowatt hour)
• Active energy / active energy (kWh)
• Reactive Energy / Blind Labor (kVarh Kilovar hour)
• Active power (kW)
• Apparent power (kVA)
. Voltage (V volt)
• Current (A ampere)
• Network frequency (Hz)

MID-certified static active and reactive 4 quadrants bidirectional energy meters suitable for Single-phase or 3-phase 3-4 wires unbalanced load systems.The large size display permits an easy reading of the energy counting (2 tariff ) and of the instantaneous power values.Moreover, the display shows the configurable partial counters (start/stop/reset) and the correct phase sequence.


2. Function description

(1)Measurement of active and reactive energy, forward and reverse energy, voltage and current

(2)3 measurement modes can be set according to the synthesis code

(3)Infrared Communication IEC1107 Protocol

(4)two display modes: automatic display and button-pressing display

(5)High accuracy: active-1.0, reactive-2.0

(6)Support max demand, 4 types of impulse output

(7)Din rail installation


3. Specifications

Type

3 Phases 4 Wires IR Meter

Reference Voltage

3*230/400V

Current

0.25-5(30)A, 5(32)A,5(40)A,5(45)A, 5(50)A, 5(80)A

Accuracy Class

Class B

Standard

EN50470-1/3

Frequency

50Hz

Impulse Constant

1000imp/kWh,1000imp/kVarh

Display

LCD6+2

Power Consumption

≤ 2W, <10VA

Starting Current

0.004Ib

Temp. Range

-20~+70℃

Average Temp.

85℃

Relative Humidity

90%

Communication

IR Communication


Function Description
