[IR] EM519171 MID Certified Three-phase IR Bidirectional Simple 3 phase Energy Meter

The EM519171 is a high-precision (Class 1) three-phase smart meter designed for accurate energy measurement. Operating at 3x230/400V and 5(80)A, this meter supports bi-directional active energy metering and complies with the latest MID standards. It features an IR port for local communication and is designed for simple DIN rail installation.

Inquire Now Next Product

1.Product Introduction

2.Key Features

Accuracy: Class 1 precision.
Voltage and Current: 3x230/400V, 5(80)A.
Metering Functionality: Supports active forward and reverse energy measurement (Bi-directional).
MID Compliance: Meets the latest MID standards.
Communication: Integrated IR (Infrared) port for local data access.
Installation: DIN rail mounting for easy installation.

3.Technical Parameters

Type	EM519168	EM519171	EM519167	EM519173
Battery	YES	N/A	YES	N/A
Blackout display	YES	N/A	YES	N/A
LCD backlight	YES	N/A	YES	N/A
Voltage	3*230/400V
Current	5(80)A
Accuracy	Class 1
Frequency	50Hz/60Hz
Display	LCD 6+2
Communication	IR		RS485
Pulse Constant	1000imp/kWh
SO Output	Indicates active power, SO output is configurable (default 1000)
Measurement model	1. Total = Forward2. Total = Reverse3. Total = Forward + Reverse (default)4. Total = Forward - Reverse5. Total = Forward - Reverse (margin)

EM519171: Precise 3-Phase Meter with IR, MID Compliant, DIN Rail Mount

Get accurate energy readings with the EM519171 Class 1 meter. Supporting bi-directional metering and meeting the latest MID standards, this 3x230/400V, 5(80)A meter includes an IR port and is designed for easy DIN rail installation.
